Doc. No. MV-S105540-00, Rev. A
Page 38 Document Classification: Proprietary Information
1.7 96-Pin aQFN Pin Assignment List - Alphabetical by Sig-
nal Name
NOTE: The 96-pin BCC package is obsolete and is no longer available. The 96-Pin aQFN package is a pin
compatible replacement for the 96-Pin BCC package.
96- Pin
BCC Pin #
96- Pin
aQFN Pin #
Pin Name 96- Pin
BCC Pin #
96- Pin
aQFN Pin #
Pin Name
22 B11 125CLK 74 A40 LED_LINK100
32 B15 AVDD 73 A39 LED_LINK1000
35 A19 AVDD 69 A37 LED_RX
36 B17 AVDD 68 B32 LED_TX
40 B19 AVDD 25 A14 MDC
45 A24 AVDD 31 A17 MDI[0]-
78 B36 AVDD 29 A16 MDI[0]+
83 A45 COL 34 B16 MDI[1]-
27 A15 COMA 33 A18 MDI[1]+
65 A35 CONFIG[0] 41 A22 MDI[2]-
64 B30 CONFIG[1] 39 A21 MDI[2]+
63 A34 CONFIG[2] 43 A23 MDI[3]-
61 A33 CONFIG[3] 42 B20 MDI[3]+
60 B28 CONFIG[4] 24 A13 MDIO
59 A32 CONFIG[5] 13 A7 NC
58 B27 CONFIG[6] 51 A28 NC
84 B39 CRS 28 B13 RESETn
1A1 DVDD 30B14RSET
6B3 DVDD 95A51RXD0
10 B5 DVDD 92 B43 RXD1
15 A8 DVDD 93 A50 RXD2
57 A31 DVDD 91 A49 RXD3
62 B29 DVDD 90 B42 RXD4
67 A36 DVDD 89 A48 RXD5
71 A38 DVDD 87 A47 RXD6
85 A46 DVDD 86 B40 RXD7
8 B4 GTX_CLK 2 B1 RX_CLK
38 B18 HSDAC- 94 B44 RX_DV
37 A20 HSDAC+ 3 A2 RX_ER
23 A12 INTn 80 B37 S_CLK-
70 B33 LED_DUPLEX 79 A43 S_CLK+
76 B35 LED_LINK10 81 A44 S_IN-
88E1111 Product Brief
Integrated 10/100/1000 Ultra Gigabit Ethernet Transceiver
Copyright © 2020 Marvell
December 2, 2020
