Signal Description
117-Pin TFBGA Pin Assignment List - Alphabetical by Signal Name
A8 S_OUT- D4 VSS
A7 S_OUT+ D5 VSS
H8 SEL_FREQ D6 VSS
L9 TCK E4 VSS
L7 TDI E5 VSS
K8 TDO E6 VSS
L8 TMS F4 VSS
M9 TRSTn F5 VSS
F1 TXD0 F6 VSS
G2 TXD1 G4 VSS
G3 TXD2 G5 VSS
H2 TXD3 G6 VSS
H1 TXD4 H4 VSS
H3 TXD5 H5 VSS
J1 TXD6 H6 VSS
J2 TXD7 J4 VSS
D1 TX_CLK J5 VSS
E1 TX_EN J6 VSS
F2 TX_ER K4 VSS
B4 VDDO K5 VSS
C2 VDDO K6 VSS
K1 VDDO L5 VSS
B9 VDDOH L6 VSS
F7 VDDOH H7 VSSC
J8 VDDOH H9 XTAL1
K9 VDDOX J9 XTAL2
L2 VDDOX
1.6 117-Pin TFBGA Pin Assignment List - Alphabetical by
Signal Name (Continued)
Pin # Pin Name Pin # Pin Name
