Marvell 88E1111 - 1.6 117-Pin TFBGA Pin Assignments

Doc. No. MV-S105540-00, Rev. A
Page 36 Document Classification: Proprietary Information
1.6 117-Pin TFBGA Pin Assignment List - Alphabetical by
Signal Name
Pin # Pin Name Pin # Pin Name
K2 125CLK A9 LED_LINK1000
B7 AVDD C9 LED_RX
M3 AVDD D9 LED_TX
M4 AVDD L3 MDC
M7 AVDD N2 MDI[0]-
M8 AVDD N1 MDI[0]+
N5 AVDD N4 MDI[1]-
B6 COL N3 MDI[1]+
L4 COMA N7 MDI[2]-
D8 CONFIG[0] N6 MDI[2]+
E9 CONFIG[1] N9 MDI[3]-
F8 CONFIG[2] N8 MDI[3]+
G7 CONFIG[3] M1 MDIO
F9 CONFIG[4] G1 NC
G9 CONFIG[5] K7 NC
G8 CONFIG[6] K3 RESETn
B5 CRS M2 RSET
C6 DVDD B2 RXD0
C7 DVDD D3 RXD1
D7 DVDD C3 RXD2
E3 DVDD B3 RXD3
E7 DVDD C4 RXD4
F3 DVDD A1 RXD5
J3 DVDD A2 RXD6
J7 DVDD C5 RXD7
E2 GTX_CLK C1 RX_CLK
M6 HSDAC- B1 RX_DV
M5 HSDAC+ D2 RX_ER
L1 INTn A6 S_CLK-
E8 LED_DUPLEX A5 S_CLK+
C8 LED_LINK10 A4 S_IN-
B8 LED_LINK100 A3 S_IN+
