Marvell 88E1111 - Page 39

Doc. No. MV-S105540-00, Rev. A
Document Classification: Proprietary Information Page 39
Signal Description
96-Pin aQFN Pin Assignment List - Alphabetical by Signal Name
82 B38 S_IN+ 4 B2 TX_CLK
75 A41 S_OUT- 9 A5 TX_EN
77 A42 S_OUT+ 7 A4 TX_ER
56 B26 SEL_FREQ 5 A3 VDDO
49 A26 TCK 21 A11 VDDO
44 B21 TDI 88 B41 VDDO
50 A27 TDO 96 A52 VDDO
46 B22 TMS 52 B24 VDDOH
47 A25 TRSTn 66 B31 VDDOH
11 A6 TXD0 72 B34 VDDOH
12 B6 TXD1 26 B12 VDDOX
14 B7 TXD2 48 B23 VDDOX
16 B8 TXD3 EPAD EPAD VSS
17 A9 TXD4 53 A29 VSSC
18 B9 TXD5 55 A30 XTAL1
19 A10 TXD6 54 B25 XTAL2
20 B10 TXD7
1.7 96-Pin aQFN Pin Assignment List - Alphabetical by Sig-
nal Name (Continued)
NOTE: The 96-pin BCC package is obsolete and is no longer available. The 96-Pin aQFN package is a pin
compatible replacement for the 96-Pin BCC package.
96- Pin
BCC Pin #
96- Pin
aQFN Pin #
Pin Name 96- Pin
BCC Pin #
96- Pin
aQFN Pin #
Pin Name
