Package Mechanical Dimensions
117-pin TFBGA Package
Table 16: 117-Pin TFBGA Package Dimensions
Dimensions in mm
Symbol MIN NOM MAX
A----1.54
A1 0.40 0.50 0.60
A2 0.84 0.89 0.94
c 0.32 0.36 0.40
D 9.90 10.00 10.10
E 13.90 14.00 14.10
D1 -- 8.00 --
E1 -- 12.00 --
e--1.00--
b 0.50 0.60 0.70
aaa 0.20
bbb 0.25
ccc 0.35
ddd 0.15
MD/ME
NOTE:
1. CONTROLLING DIMENSION: MILLIMETER.
2. PRIMARY DATUM C AND SEATING PLANE ARE DEFINED BY THE
SPHERICAL CROWNS OF THE SOLDER BALLS.
3. DIMENSION b IS MEASURED AT THE MAXIMUM SOLDER BALL
DIAMETER, PARALLEL TO PRIMARY DATUM C.
