Mase IS 8 - Page 31

IS 8 - 9.5 9.2 - 10.2
mase
87
Rev. / Rel.
FIG.
6 / 7
CRUSCOTTO COMANDI A DISTANZA
CON STRUMENTI
REMOTE CONTROL PANEL WITH
INSTRUMENTS
IS 8 - 9.5/ 9 - 10.2
5LI &RG 4W\ 'HVFUL]LRQH 'HVFULSWLRQ
010878 1 KIT COMANDO A DIST. CON STRUMENTI REMOTE CONTROL PANEL KIT WITH INSTRUMENTS
1 010879 1 QUADRO COMANDO A DISTANZA REMOTE CONTROL PANEL WITH INSTRUMENTS
1a 012396 1 PANNELLO PANEL
1b 41669 1 ADESIVO LABEL
1c 32402 1 INTERRUTTORE START/0/STOP START/0/STOP BUTTON
1d 32412 1 TERMOMETRO 12V 120°C WATER THEMPERATURE GAUGE
1e 32413 1 MANOMETRO 12V 5BAR OIL PRESSURE GAUGE
2 011083 1 CAVO COMPLETO 20MT 20m CABLE
