Mash Five Hundred 400 - I Main Technical Data

1
I、Main Technical Data
Length
2130mm
Bore * Stroke
85.0×70.0
Width
740mm
Compression ratio
8.8:1
Height
1130mm
Max power
19.5Kw/7000R/min
Wheelbase
1420mm
Max torque
30.0N.m/5500r/min
Gross weight
160kg
Idle Speed
1500±150r/min
Max loading weight
151kg
Displacement
397.2cc
Front wheel type
100/90-19/280
Spark plug type
DPR8Z
Rear wheel type
130/70-18/290
Spark plug gap
0.6mm-0.7mm
Lubricant volume
2.2L
Valve gap
Intake valve: 0.07-0.10 mm
Fuel tank volume
13L
Exhaust valve: 0.08～0.12mm
End level transmission ratio
2.533
Overcurrent protection
15A/10A
Initial level transmission ratio
2.667
Battery
12V 9Ah
Headlight
12V55W
Taillight/Brake signal light
12V 5W/21W
Position indicator
12V 5W
Turning signal light
12V 10W×4
Turning instruction light
12V 1.7W
Meter light
12V 3W
Far-reaching light instruction
12V 1.7W
Minimum ground clearance
160mm
