7. Relay/OC Outputs:
Following function can be set for Relay/OC outputs.
Relay OC Logic (Direction):
Relay Logic means Relay contact can be changed from NO – NC OR
NC – NO. If relay logic is selected Normal, when Fault occur Relay contact will
change from NC to NO. If relay logic is selected Fail Safe, when Fault occur Relay
contact will change from NO to NC.
Relay/OC Function:
Relay/OC function can be selected as ALARM or TRIP.
Relay/OC Delay:
A time delay can be provided for the actual output.
Relay/OC Open Sensor:
Open sensor up scale or down scale can be selected for each relay/OC
output.
Relay/OC Mapping:
Refer Menu layout LEVEL - 2
Relay/OC Types:
Various alarm/OC operations are shown in the reference figure. (High, Low,
Very High- High, Low-Very Low, High- Low)
For relay/OC types selection Refer Menu layout LEVEL – 2.
