Masibus 8208 - Modbus Parameter Details for Read Output Status Register

8-CHANNEL SCANNER-8208
REF NO: m82A/om/101 masibus
Issue NO: 08
User‟s Manual Page 33 of 42
Channel-3
14
Span Calibration
Channel-4
49014
INT
-
-
W
15
Span Calibration
Channel-5
49015
INT
-
-
W
16
Span Calibration
Channel-6
49016
INT
-
-
W
17
Span Calibration
Channel-7
49017
INT
-
-
W
18
Span Calibration
Channel-8
49018
INT
-
-
W
Modbus Parameter Details for Read Output Status Register:
SR.
NO.
Parameter
Absolute
Address
Parameter
Type
Access Type
1
Alarm.1 Channel-1
1
BIT
R
2
Alarm.1 Channel-2
2
BIT
R
3
Alarm.1 Channel-3
3
BIT
R
4
Alarm.1 Channel-4
4
BIT
R
5
Alarm.1 Channel-5
5
BIT
R
6
Alarm.1 Channel-6
6
BIT
R
7
Alarm.1 Channel-7
7
BIT
R
8
Alarm.1 Channel-8
8
BIT
R
9
Alarm.2 Channel-1
9
BIT
R
10
Alarm.2 Channel-2
10
BIT
R
11
Alarm.2 Channel-3
11
BIT
R
12
Alarm.2 Channel-4
12
BIT
R
13
Alarm.2 Channel-5
13
BIT
R
14
Alarm.2 Channel-6
14
BIT
R
15
Alarm.2 Channel-7
15
BIT
R
16
Alarm.2 Channel-8
16
BIT
R
17
RELAY STATUS-1
17
BIT
R
18
RELAY STATUS-2
18
BIT
R
19
RELAY STATUS-3
19
BIT
R
20
RELAY STATUS-4
20
BIT
R
21
Auto/Manual Mode
21
BIT
R/W
22
Acknowledge For Relay
22
BIT
W
23
Unused
-
-
-
24
Unused
-
-
-
NOTE: For Auto/Manual Mode, to set Manual mode bit value = 1 and to set Auto
mode bit value = 0.
For Acknowledgement function, to give acknowledge for relay bit value = 1.
