Masibus 8208 - Output Status Register Parameters

8-CHANNEL SCANNER-8208
REF NO: m82A/om/101 masibus
Issue NO: 08
User‟s Manual Page 32 of 42
SR.
NO.
Parameter
Absolute
Address
Parameter
Type
Min
Value
Max Value
Access
Type
NOTE
93
RLY Latch
40093
INT
0
1
R/W
94
RLY Group
40094
INT
0
1
R/W
95
Scan Rate
40095
INT
1
250
R/W
96
Auto CJC
40096
INT
0
1
R/W
97
Fix CJC
40097
INT
0
600
R/W
98
Machine ID
40098
INT
1
247
R/W
99
Baud Rate
40099
INT
0
1
R/W
100
Parity/Stop Bit
40100
INT
0
3
R/W
101
Timeout
40101
INT
10
60
R/W
102
PV Scale Retransmission
40102
INT
0
1
R/W
103
Retransmission Type
40103
INT
0
4
R/W
104
Retransmission Direction
40104
INT
0
1
R/W
105
Retransmission CH - 1
40105
INT
0
1
R/W
106
Retransmission CH - 2
40106
INT
0
1
R/W
107
Retransmission CH - 3
40107
INT
0
1
R/W
108
Retransmission CH - 4
40108
INT
0
1
R/W
109
Retransmission CH - 5
40109
INT
0
1
R/W
110
Retransmission CH - 6
40110
INT
0
1
R/W
111
Retransmission CH - 7
40111
INT
0
1
R/W
112
Retransmission CH - 8
40112
INT
0
1
R/W
113
Retransmission Value
40113
0
1
R/W
114
Retransmission Channel
selection
40114
INT
1
8
R/W
115
Password
40115
INT
0
9999
R/W
116
Future use
117
Future use
118
Future use
Sr.
No.
Parameter
Absolute
Address
Parameter
Type
Min
Value
Max Value
Access
Type
NOTE
1
Calibration Password
49001
INT
0
65000
W
2
Ambient Calibration
49002
INT
-
-
W
3
Zero Calibration
Channel-1
49003
INT
-
-
W
4
Zero Calibration
Channel-2
49004
INT
-
-
W
5
Zero Calibration
Channel-3
49005
INT
-
-
W
6
Zero Calibration
Channel-4
49006
INT
-
-
W
7
Zero Calibration
Channel-5
49007
INT
-
-
W
8
Zero Calibration
Channel-6
49008
INT
-
-
W
9
Zero Calibration
Channel-7
49009
INT
-
-
W
10
Zero Calibration
Channel-8
49010
INT
-
-
W
11
Span Calibration
Channel-1
49011
INT
-
-
W
12
Span Calibration
Channel-2
49012
INT
-
-
W
13
Span Calibration
49013
INT
-
-
W
