Retransmission output calibration (Voltage/current output):-
Press set key repeatedly, till PV display shows message rtr.Z (retransmission output
zero calibration).
SV display shows the value being outputted on Retransmission output terminals.
Measure the value using a highly accurate digital multi meter. Use Inc/Shift key to
correct the displayed reading to the measured value. Press ENT key. The controller
will store zero calibration value. Press MENU key to calibrate retransmission output
span calibration menu.
PV shows the message rtr.S (retransmission output span calibration). SV display
shows the value being outputted on retransmission output terminals. Measure the
value. Use Inc/Shift key to correct the displayed reading to the measured value.
Press ENT key. When the calculations are over, the new calibration values are stored
automatically. Calibration for Retransmission output is over. Press MENU key to
calibrate other parameters or press Escape key to come out to normal operation.
Group Calibration Detail:-
NOTE:
If you calibrate any input from any group i.e. I/P E-TC from Group – 1 than
calibration is not required for other input types from Group-1.
Group
NO
Input type
Calibration for input
1
E,J,K,T,N,0-
75mv,0-100mv
Either of any input
2
Pt-100(RTD)
Specific input
3
B,R,S,-10 to 20mv
Either of any input
4
0-2V,0.4-2V,4-
20mamp,0-
20mamp
Either of any input
5
0-10V,0-5v,1-5V
Either of any input
