8-CHANNEL SCANNER-8208
REF NO: m82A/om/101 masibus
Issue NO: 08
User‟s Manual Page 8 of 42
3. Hardware Specification Detail:
Input type: Universal input type
Thermocouple, RTD, Millivolt, Voltage, Current INPUT types are software selectable.
Applicable Standards: DIN (ITS-90) for Thermocouple and RTD
Type
Rang e
Accuracy
Resolut ion
E
-200 t o 100 0  C
+0.1% of instrument range
+ 1 digit for temperature
equal to or higher than 0º C
+ 0.25% of instrument
range + 1 digit for
temperature
below 0º C
+0.25% of instrument range
+ 1 digit(B,R,S TYPE TC)
0.1  C
(1 C B,R,S
TYPE TC)
J
-200 t o 120 0  C
K
-200 t o 137 0  C
T
-200 to 400  C
B
450 to 180 0 C
R
0 t o 17 50C
S
0 t o 17 50C
N
-200 t o 130 0°C
RTD
-199.9 to
850.0 C
+ 0 .1 % o f i nstrume nt
ran g e + 1 di git
0 t o 75 mV
-1999 t o 99 99
+ 0 .1 % o f rang e + 1
di gi t
1 C ou nt
0 t o 10 0mv
0.4 t o 2V
0 t o 2V
0-20 mA *
4-20 mA *
0 t o 5V
1 t o 5V
0 t o 10 V
-10 to
20mV
*For DC current input, 100 Ohms (0.1%, 25 ppm) shunt resistor must be connected
externally. For DC current and Voltage input, Scaling is possible and decimal point is
selectable.
Sampling Period: 100mSec for TC and Linear Input, 200mSec for RTD Input.
Resolution: 17-bit
Burnout detection: Functions for TC, RTD, linear input signal. (It detects whether
sensor is connected or not) ALL Relay output can be selected for Burnout Condition.
i.e. Open sensor Up scale or Down Scale
Measurement current (RTD): 1milli Ampere
