Number Quantity Part code Item
1 5 C200-1600-12 Cap nut
2 1
C200-0100-08 Rotor Hi-Endurance, A494/CY5SnBiM
C200-0100-06 Rotor Hi-Endurance, A276/CF10SMnN
C200-0120-08 Rotor Lo-Shear, A494/CY5SnBiM
C200-0120-06 Rotor Lo-Shear, A276/CF10SMnN
3 1 C200-0200-10 Front housing
4 1 C200-0300-10 Middle housing
5 1 C200-0350-10 Back housing
6 - - (Not required)
7 1 C200-2320-80 Lip seal
8 4 C200-2220-12 Hexagon screw
9 1 C200-2400-25 Tapered roller bearing
10 1 C200-1401-30 Shim ring
11 1 C200-1400-12 Support
12 1 C200-6000-50 Oil vent valve
13 1 C200-2700-25 Tab washer
14 1 C200-2800-25 Locknut
15 1 C200-1500-12 Cover for bearing
16 2 — Nozzle (on customer request)
17 1 C200-3250-12 Shaft key
18 1 C200-0400-## Gate
19 4 C200-0301-12 Pin
20 1 C200-1000-16 Shaft
21 1 C200-3200-12 Shaft key
22 1 C200-2300-80 Lip seal
23 3 C200-2900-12 Hexagon screw
24 1 C200-3000-80 O-Ring
25 1 C200-2600-25 Tapered roller bearing
26 1 C200-2000-12 Drain plug
27 1 C200-3800-51 Oil sight glass
28 1 C200-5000-25 Snap ring
29 8 C200-1900-12 Hexagon socket head cap screw
30 1 C200-1300-12 End shield
31 1 C200-1301-12 Foot plate
32 - - (Not required)
33 - - (Not required)
34 - - (Not required)
35 2 C200-1850-12 Stud
Number Quantity Part code Item
36 2 C200-1750-## Seal, pump housing
37 3 C200-1800-12 Stud
38 2 C200-5010-12 Pin
39 4 C200-5001-12 Hexagon socket head cap screw
40 1 C200-1100-10 Locking screw
41 1 C200-1752-## Sealing for locking screw
42 2 C200-1805-12 Hexagon nut
43 - - (Not required)
44 1 C200-3701-33 Copper seal
45 1 C200-1150-12 Disc spring
46 1 C200-1112-80 O-ring
47 - - (Not required)
48 6 C200-2100-33 Sealing ring
49 6 C200-9002-12 Threaded plug
X 1 Sealing system
