masosine Certa C100 - Atmospheric Side of Double Mechanical Seal

C100
Number Quantity Part code Item
70 1 C100-5310-10 Dynamic ring holder
71 1 C100-5340-41 Dynamic face
72 1 C100-5345-41 Static face
74 1 C100-5311-## O-Ring
75 1 C100-5341-## O-Ring
76 1 C100-5346-## O-Ring
79 1 C100-5320-10 Spring assembly
X 1
See C100 on
page53
Sealing system
C200
Number Quantity Part code Item
70 1 C200-5310-10 Dynamic ring holder
71 1 C200-5340-41 Dynamic face
72 1 C200-5345-41 Static face
74 1 C200-5311-## O-Ring
75 1 C200-5341-## O-Ring
76 1 C200-5346-## O-Ring
79 1 C200-5320-10 Spring assembly
X 1
See C200 on
page53
Sealing system
C250
Number Quantity Part code Item
70 1 C250-5310-10 Dynamic ring holder
71 1 C250-5340-41 Dynamic face
72 1 C250-5345-41 Static face
74 1 C250-5311-## O-Ring
75 1 C250-5341-## O-Ring
76 1 C250-5346-## O-Ring
79 1 C250-5320-10 Spring assembly
X 1
See C250 on
page53
Sealing system
56 m-certa-en-08
21.5 Atmospheric side of double mechanical seal
