24
Masport F43/F28 Freestanding Gas Heater
MAINTENANCE
5) Carefully remove the logs, embers and rockwool.
6) At this point you should disconnect the gas at the valve.
7) Remove the burner by removing the four 1/4" hex head
screws. See diagram below.
Note: Use a magnetic type screwdriver.
8) Remove eight 1/4" hex head screws holding the burner
tray assembly in place.
9) Carefully lift the burner tray assembly out.
F43 Burner
F28 Burner
10) To replace the burner tray assembly, simply reverse
these instructions.
