Masport KRONOS Multi Fuel - Floor Protector (Hearth) Requirements Parallel Installation

PARALLEL INSTALLATION
MINIMUM FLOOR PROTECTOR DIMENSIONS IN mm
# DIMENSIONS IN THE TABLE ARE VALID ONLY WHEN THE FIRE IS EXACTLEY AT ITS MINIMUM
ALLOWABLE WALL CLEARANCE.
Flue
Shield
Floor
Protector
height
A# C# D F I J K# P2 P3 W
Floor
Protector
Type Ø
*
170
300 100 377 600 900 1013 543 207 700 ASH
Flue
Shield
Floor
Protector
height
A# C# D F I J K# P2 P3 W
Floor
Protector
Type Ø
FLOOR PROTECTOR (Hearth) REQUIREMENTS
NOTE: Where a fan is being fitted, you may prefer to increase the ‘A’ dimension to 100 mm to provide easier
access for servicing. If so, the amount you add to ‘A’ to bring it to 100 mm must also be added to the ‘C’ and
‘S’ dimensions.
# Valid only when the fire is exactly at its minimum allowable wall clearance.
Ø for minimum constructional requirements see general installation instructions.
MODEL
AUSTRALIA - ALL WITH FLUE HEATSHIELD
NEW ZEALAND
MODEL
* KRONOS double skin S/S polished 1200 mm shield
Kronos
Multi Fuel
O:\W-F INSTALLATION SPECIFICATIONS\Individual Installation Data Sheets\INSTALLATION
SPECIFICATIONS INDIVIDUAL LOGAIRE\KRMM0738_Kronos Multi Fuel_Data Sheet-10-09-07.xls
