THE INSTALLATION AND OPERATING INSTRUCTIONS IN THIS
MANUAL APPLY TO THE FOLLOWING WOODFIRES:-
Free standing models:-
MASPORT HORIZON
MASPORT LE 2000, 2000/S, 2000/W
MASPORT LE 3000, 3000/S, 3000/W (Series 2 models)
MASPORT LE 5000, 5000/S, 5000/W (Series 2 models)
MASPORT SIENA, SIENA/S
MASPORT VERONA
MASPORT PANORAMA (Series 2) and (Series 3)
MASPORT GRANDVIEW
MASPORT TORONTO
Fireplace Insert models:-
MASPORT LE 3000 PROVINCIAL (Series 2)
MASPORT LE 3000/S PROVINCIAL (Series 2)
MASPORT LE 3000/W PROVINCIAL (Series 2)
MASPORT LE 3000 PROVINCIAL (Clean Air Zone)
MASPORT LE 7000 PROVINCIAL (Australia)
Note: Models without a suffix have been emission tested for Australia.
Models /S have been emission tested for N.Z. without water boosters.
Models /W have been emission tested for N.Z. with water boosters.
CONTENTS OF LOOSE PARTS BAG
(Note: You may not need all these parts for your installation)
Part No. Quantity Description Where Used
501682 10 M6 Hexagon Nut 4 — Pedestal front to pedestal sides
4 — Firebox to pedestal
2 — ‘L’ Brackets to pedestal
501703 4 M6 Flat Washer 4 — Firebox to pedestal
501815 4 M6 x 35mm Hex. Set Screw 4 — Firebox to pedestal
501959 6 M6 x 12mm Hex. Set Screw 4 — Pedestal front to pedestal sides
2 — ‘L’ Brackets to pedestal
503005 4 Self Threading Screw —
12mm long, zinc plated finish
4 — Heat shield to top of pedestal
503259 4 Self Threading Screw —
12mm long, black finish
4 — Pedestal rear panel to pedestal
503388 2 ‘C’ Nut (Spire # SNU 0537) 2 — Seismic restraint bar to pedestal
503459 2 Self Threading Screw —
25mm long
2 — Seismic restraint bar to pedestal
595381 1 Installing & Operating Manual
986413 2 ‘L’ Bracket 2 — Sides or rear of pedestal
6 m m 1 2 m m 2 5m m 3 5m m
