CV Description Default An Value Note
5+6 Programming in Register Mode:
Register 6 = CV No.
Register 5 = Value
--- --- CV5 and CV6 are not affected
7 Software Version 20 --- read only
7 Decoder Reset Functions
(5 Ranges Available)
--- 55
66
77
111
122
133
reset basic setting
reset motor setting
reset lights and functions
reset CV131 - CV167
reset CV171 - CV199
reset CV200 - CV212
see attachment 6
8 Manufacturer ID 123 --- read only
9 Motor Frequency 0 √ 0 ... 3 0=16 kHz, 1=2 kHz,
2=250 Hz, 3= 60 Hz
13 Function Outputs in Analog Mode
(on if Value Set)
3 √ 0 ... 255 F1 = 1, F2 = 2;
F3 = 4, F4 = 8;
F5 = 16, F6 = 32;
F7 = 64, F8 = 128
add the values of the desired
functions!
17 Long Loco Address (High Byte)
18 Long Loco Address (Low Byte)
128 128 ...
10239
high loco address active,
if CV29-Bit5 = 1
29 Configuration Table NMRA 4 √ see attachment 1
49 Configuration Table Massoth 3 √ see attachment 2
50 Light: Dimming Value (PMW) 32 √ 1 ... 32 32 = full track voltage
51 Front Light: Command Allocation 128 see attachment 3
52 Rear Light: Command Allocation 64 see attachment 3
53 F1 + F2 Dimming Value 32 √ see attachment 4
54 F1: Command Allocation 1 see attachment 3
55 F1: Special Function 0 √ see attachment 5
56 F2: Command Allocation 2 see attachment 3
57 F2: Special Function 0 √ see attachment 5 + 5a
58 Pause Time for Stop with Reversing 0 √ 0 ... 255 0.5 sec per value
59 Switching Speed (Half Speed) Command
Allocation
8 0 ... 16 0 = Off, 1…16 = F-key
60 PI-Load Control: Maximum Readjustment
Factor
2 √ 1 ... 255 large value = strong
readjustment
61 PI-Load Control: Readjustment
Retardation
60 √ 1 ... 255 large value = slow readjustment
62 PI-Load Control: Readjustment Strength 255 √ 1 ... 255 1 = fast limitation
