8.6.Attachment 6: CV 7 Default Settings at Resets
Write the desired reset value into CV7 (software version of the decoder) to reset the decoder settings to the
basic settings. The reset values 111 and 122 reset the sound settings of the sound decoder. These values vary
with the sound version and are therefore not listed.
RESET CV-Values on Reset Programing
55 1=3, 17=0, 18=128, 29=4, 49=2, 58=0, 59=8
66 2=2, 3=3, 4=3, 5=255, 6=64, 9=0, 60=4, 61=60, 62=255, 64=9
77 13=0, 50=32, 51=128, 52=64, 53=32, 54=1, 55=0, 56=2, 57=0, 112=32, 113=3, 114=0, 115=4,
116=0, 117=5, 118=0, 119=6, 120=0
111 CV131 - CV167 Reset of Sound Functions (values vary with sound type)
122 CV171 - CV199 Reset Standing Phase Sounds (values vary with sound type)
133 CV200 - CV220 Reset Volume Settings
8.7.Attachment 7: Basic Values of Freely Programmable Driving Curve (CV67…CV94)
The Programmable driving curve is set to the setting below as basic setting. This setting is not subject to the
reset functions.
Basic values of freely progammable driving curve (CV + Value)
67=6, 68=8, 69=10, 70=13, 71=16, 72=19, 73=22, 74=26, 75=31, 76=36, 77=42, 78=48, 79=54, 80=60,
81=68, 82=76, 83=84, 84=92, 85=102, 86=112, 87=124, 88=136, 89=152, 90=168, 91=188, 92=208, 93=228,
94=232
8.8.Attachment 8: (CV149) – Massoth-Sound-Configuration
Bit Off (Value=0) Application On Value Note
0 Random Generator Off Random Generator Active 1
1 Standing Phase Noise Off Standing Phase Noise
Active
2
2 Standard Driving Sound Load-Dependent Sound 4 rolling noise during coasting
3 Cylinder Valves Closed Cylinder Valves Open 8 only steam locos during start
of movement
4 Contacts Standard Reed Contact Inputs
Direction Sensitive
16
5 Automatic Side Noises Off Automatic Side Noises
Active
32
6 Start Signal Delay Off Start Signal Delay On 64 since V1.2 (written in CV 7)
7 Not Used
9.Decoder programming + update
The eMOTION XLS Sound Decoder supports all programming methods in accordance with the latest
NMRA/DCC standards. Please note that not all of the DCC systems currently available can be programmed
according to this standard. The manufacturer of your DCC system should give you in-depth information.
Choose the programming method applicable to your digital system. The eMOTION XLS Sound Decoder
confirms every successful programming cycle with a short beep via the loudspeaker. This ensures the correct
reception and accomplishment of the programming command.
eMOTION XLS Sound Decoder 28
