8.Attachment 1: (CV29) - NMRA-Configuration
Bit Off (Value=0) Application On Value Note
0 Standard Driving Direction Reverse Driving Direction 1
1 14 Speed Steps 28 Speed Steps 2 automatic recognition of 128
speed steps
2 Digital Operation Only Digital + Analog Operation 4
3 Not Used
4 Internal Driving Curve Programmable Driving
Curve
16 CV 67 - 94
5 Short Address (CV1) Long Address (stored in
CV17+18)
32
6 not used
7 not used
8.1.Attachment 2: (CV49) - Massoth-Configuration
Bit Off (Value=0) Application On Value Note
0 Parallel Data Transfer Only Seriell + Parallel Data
Transfer
1 automatic detection of seriell/
parallel
1 Digital Load Control = Off Digital Load Control = On 2
2 Analog Load Control = Off Analog Load Control = On 4
3 F1-Output Standard Function Fast Pulse String (P-Update)
on F1
8 Bit3 "on" only with Bit0 "on"
4 Not Used
5 Not Used
6 Not Used
7 Not Used
8.2.Attachment 3: Switching Output Commands (CV51, 52, 54, 56, 113, 115, 117, 119)
Value Application Note
0 ... 16 0 = Switch Function with Light Key, 1...16 = Switch
Function with F-Key No. 1-16
+ 64 Switching Output "on" in Reverse Only additional value must be added
+ 128 Switching Output "on" in Standard Driving Direction
Only
additional value must be added
