FRONT PANEL DESCRIPTION
c
d
e
f
g
h
Display
3 1/2 digit, 7 segment, 15mm high LCD.
Rotary switch
This switch is used to select functions and desired
ranges as well as to turn on/off the meter.
Hold button
When this button is pushed, the display will keep the last
reading and “
”
symbol will appear on the LCD until
pushing it again.
“10A” jack
Plug in connector for red test lead for 10A measurement.
“COM” jack
Plug in connector for black (negative) test lead.
“VΩmA” jack
Plug in connector for red (positive) test lead for voltage,
resistance and current (except 10A) measurements.
SPECIFICATIONS
Accuracy is specified for a period of one year after calibration
and at 18 to 28℃(64°F to 82°F) with relative humidity to 80%.
GENERAL
Maximum voltage :CATⅡ 600V
Fuse protection :F 200mA/250V
Power :9V battery, NEDA 1604 or 6F22
Display : LCD, 1999 counts, updates 2-3/
sec.
Measuring method :Dual-slope integration A/D
converter
Overrange Indication :Only figure “1” on the display
Polarity indication :“-”displayed for negative polarity
Operating Environment :0 to 40℃
Storage temperature :-10℃ to 50℃.
Low battery indication :“
”appears on the display
Size :138mm×69mm×31mm
Weight : Approx.160g.
-4-
