Page #4 background imageLoading...
Page #4 background image
Alternating current/ voltage
Directive current/voltage
Diode
Buzzer
Auto rangi
ng mode
Relative measurement
Use
LPF
No use LPF
Data hold
Low battery indicator
-
7
-
%
Duty cycle
mV
V
Voltage unites
mA
A
Current unites
Temperature unite
nF
µF
Capacitance unite
kΩ
MΩ
Resistance unites
Hz
kHz
Frequency unites
3. Specification
3-1
General feature
Auto ranging Digital Clamp Meter. But the meter may select manual Function
mode by ‘RANGE’button.
● 3 1/2 digit(200 count) LCD display
● Over load indication
‘OL’symbol will displayed on the LCD.
● Jaw opening capability: 32mm
● Low battery indication : battery symbol is appears on the LCD.
Auto power OFF: If the meter is idle for more than 15 minutes, the meter
automatically turns the power off.
● Sampling rate: 2times/s
● Power supply: 1.5V battery(AAA type) x 3pcs.
● Operating temperature & Humidity: 0 to 40 ; < 80% RH
● Storage temperature & Humidity : -10 to 50 ; <70% RH
● Dimension(L x W x H) & Wight : 260 x 92 x 55mm; Approx. 400g
- 8 -
3-2
Electrical Specification
[1] AC Current
Range Resolution Accuracy
40mA 0.01mA
50 ~ 60Hz
(30~50Hz,
