Mastech MS5308 - Capacitance Measurement Scope

Page 6 of 17
Table 2 Capacitance measurement scope
Note: This accuracy is the measurement standard. When D
<0.1, if D> 0.1, it should be multiplied by the extraction of a
root of 1 + D
2
Measurem Measurement Measure Resoluti Accuracy
C
S
/C
P
100Hz/120 20.000nF 1pF 1.0%+5d
100Hz/120 200.00nF 0.01nF 0.5%+5d
100Hz/120 2000.0nF 0.1nF 0.5%+5d
100Hz/120 20.000uF 1nF 0.5%+5d
100Hz/120 200.00uF 0.01uF 1.0%+5d
100Hz/120 2000.0uF 0.1uF 2.0%+5d
100Hz/120 20.00mF 0.1mF 2.0%+5d
1kHz 2000.0pF 0.1pF 1.0%+5d
1kHz 20.000nF 1pF 1.0%+5d
1kHz 200.00nF 0.01nF 0.5%+5d
1kHz 2000.0nF 0.1nF 0.5%+5d
1kHz 20.000uF 1nF 0.5%+5d
1kHz 200.00uF 0.01uF 1.0%+5d
1kHz 2000.0uF 0.1uF 1.0%+5d
10kHz 200.00 0.01pF 1.0%+5d
10kHz 2000.0pF 0.1pF 1.0%+5d
10kHz 20.000nF 1pF 1.0%+5d
10kHz 200.00nF 0.01nF 1.5%+5d
10kHz 2000.0nF 0.1nF 2.0%+5d
100kHz 200.00 0.01pF 2.0%+5d
100kHz 2000.0pF 0.1pF 1.0%+5d
100kHz 20.000nF 1pF 2.0%+5d
100kHz 200.00nF 0.01nF 5.0%+5d
