Mastech MS8211D User Manual

08
3.2 Electrical Specifications
0.1mV
0.001V
200mV
0.01V
0.1V
600V
Range
Resolution
Accuracy
2V
20V
200V
1V
± (0.7% of rdg + 2 digits)
- Input Impedance: 10MΩ
- Overload Protection: 200mV range: 250V DC or
AC rms, 2V-600V ranges: DC 600V or AC 600V rms.
- Max. Input Voltage: 600V DC
- Rotatable Probe Socket
Rotating the probe in or out of the meter.
- Protection Ring
To keep the hand from the probe behind the ring.
3. SPECIFICATIONS
Accuracy is specified for a period of year after calibration
and at 18°C to 28°C(64°F to 82°F) with relative humidity
to 75%.
3.1.1 Environment conditions:
600V CAT. II
Pollution degree: 2
Altitude < 2000m
Operating temperature: 0~40 , 32°F~122 80%RH,
<10 non-condensing)
Storage temperature: -10~50 14 ~122 70% RH,
battery removed)
°C °F<
°C
°C, °F °F(<
3.1.2 Max. Voltage Between Terminals And Earth Ground:
600V DC or AC
3.1.4 Display: 20mm LCD
3.1.5 Max. Show Value: 1999 (3 1/2)
3.1.6 Polarity Indication: ‘-’indicates negative polarity.
3.1.7 Overrange Indication: Display ‘OL’
3.1.8 Sampling Time: approx. 0.4 second
3.1.9 Unit showing: showing of function and electrical capacity.
3.1.10 Low Battery Indication: ‘ ’displayed
3.1.12 Auto power off time: 15 min.
3.1.13 Power Supply: 1.5V×2 AAA battery.
3.1.14 Dimension: 208×38×29 mm
3.1.15 Weight: approx. 110g (including battery)
3.1.3 Auto ranges and manual range.
3.1.11 Fuse Protection: mA: resettable fuse
Circumstance Temperature: 23±5°C Relative
Humidity: < 75%
3.2.1 DC Voltage
3.2.2 AC Voltage
0.1mV
0.001V
200mV
0.01V
0.1V
600V
Range
Resolution
Accuracy
2V
20V
200V
1V
± (1.0% of rdg + 3 digits)
± (0.8% of rdg + 3 digits)
- Input Impedance: 10MΩ
- Overload Protection: 200mV range: 250V DC
or AC rms, 2V-600V ranges: DC 600V or AC 600V rms.
- Frequency Range: 40 to 400Hz
- Response: Average, calibrated in rms of sine wave.
- Max. Input Voltage: 600V rms AC
3.1 General specifications
