5. Turn on the power of the measured circuit, and then read the display. Be sure to note the
measurement units at the right side of the display (mA or A). When only the figure "1" displayed, it
indicates overrange situation and the higher range has to be selected.
6. Turn off the power of the measured circuit and discharge all the high voltage capacitors. Remove the
test leads and recover the measured circuit.
4 TECHNICAL SPECIFICATIONS
4.1 GENERAL SPECIFICATIONS
( Environment conditions:
1000V
CAT.
II and 600V
CAT.
III
Pollution degree: 2
Altitude < 2000m
Operating temperature:
0~40 ℃ , 32 ℉ ~122 ℉ (<80% RH, <10 ℃ noncondensing)
Storage temperature:
-10~60 ℃ , 14 ℉ ~140 ℉ (<70% RH, battery removed)
( Temperature Coefficient:
0.1 ( (specified accuracy) / ℃ (<18 ℃ or >28 ℃ )
( MAX. Voltage between terminals and earth ground:
750V AC rms or 1000V DC.
( Fuse Protection: mA: Resettable fuse (F200mA/250V)
( Sample Rate: 3 times/sec for digital data.
( Display: 3 1/2 digits LCD display. Automatic indication of functions and symbols.
( Over Range indication: LCD will display "1".
( Low battery indication:
The " " is displayed when the battery is under the proper operation range.
( Polarity indication: " ( " displayed automatically.
( Power source: 9V
( Battery type: NEDA 1604, 6F22, or 006P.
( Dimensions: 195(L) ( 92(W) ( 55(H) mm.
( Weight: 380g. Approx. (battery included).
4.2 Measurement specifications
Accuracy is specified for one year after calibration, at operating temperatures of 18 ℃ to 28 ℃ , with
relative humidity at 0% to 75%.
Accuracy specifications take the form of: ± (% of Reading + Number of Least Significant Digits)
4.2.1 DC Voltage
Rang
e
Resolutio
n
Accuracy
200m
V
0.1mV
± (0.5% of rdg +1 digit)
2V 1mV
20V 10mV
200V 100mV
1000
V
1V ± (0.8% of rdg +2 digits)
