l Auto power-off
l Operating temperature: 0℃～50℃
l Storage temperature: -40℃～60℃
l Low battery indication: symbol “ ” displayed on the upper left of the LCD.
l Dimensions: 70(W)×155(L)×39(H)mm
l Weight: approx. 250g
SPECIFICATIONS
Accuracy is specified for a period of one year after calibration and at 18℃～28℃ with relative
humidity to 75%.
Accuracy specifications take the form of:
±([% of Reading]+[number of Least Significant Digits])
DC VOLTAGE
Range Resolution Accuracy
200mV 0.01mV
±(0.05%+3)
2V 0.1mV
±(0.1%+3)
20V 1mV
±(0.1%+3)
200V 10mV
±(0.1%+3)
1000V 0.1mV
±(0.15%+5)
Input impedance: 10MΩ
Overload protection: Range 200mV: 250Vdc or ac rms
Other ranges: 700V rms or 1000V peak
AC VOLTAGE
Range Resolution
Accuracy (50～60Hz) Accuracy (40～1000Hz)
2V 0.1mV
±(0.5%+10) ±(1.0%+10)
20V 1mV
±(0.6%+10) ±(1.0%+10)
200V 10mV
±(0.6%+10) ±(1.0%+10)
700V 0.1V
±(0.8%+15) ±(1.2%+15)
Input Impedance: 2MΩ
Overload protection: 700V rms or 1000V peak
Indication: Average (rms of sine wave)
DC CURRENT
Range Resolution Accuracy
2mA 0.1µA
±(0.5%+5)
20mA 1µA
±(0.5%+5)
200mA 10µA
±(0.8%+5)
10A 1mA
±(2.0%+10)
Overload protection: 250mA/250V fused (range 10A unfused)
Max. input current: 10A (Can not last for more than 10 seconds.)
AC CURRENT
Range Resolution Accuracy
2mA 0.1µA ±(0.8%+10)
20mA 1µA
±(0.8%+10)
