200mA 10µA
±(1.2%+10)
10A 1mA
±(2.5%+10)
Overload protection: 250mA/250V fused (range 10A unfused)
Max. input current: 10A (Can not last for more than 10 seconds.)
Frequency: 40Hz～1000Hz
Indication: Average (rms of sine wave)
RESISTANCE
Range Resolution Accuracy
200Ω 0.01Ω ±(0.5%+10)
2KΩ 0.1Ω ±(0.3%+5)
20KΩ 1Ω ±(0.3%+2)
200KΩ 10Ω ±(0.3%+2)
2MΩ 100Ω ±(0.3%+2)
20MΩ 1KΩ ±(0.5%+2)
200MΩ 10KΩ ±[ 5.0%(rdg-1000)+10 ]
Overload protection: 250Vac rms
Note: In range 200MΩ, it is normal that number 1000 is displayed on the LCD when the test
leads is shorted, and the number must be subtracted from the reading while making measurement.
CAPACITANCE
Range Resolution Accuracy
2000pF 0.1pF
±(4.0%+10)
20nF 1pF
±(4.0%+10)
200nF 10pF
±(4.0%+10)
2µF 100pF
±(4.0%+10)
20µF 1nF
±(4.0%+10)
FREQUENCY
Range Resolution Accuracy
20KHz 1Hz
±(1.5%+5)
Overload protection: 250Vac rms
Input voltage: 200mV～10V rms
AUDIBLE CONTINUITY
Range Description
If the resistance under measurement is less 70Ω, the built-in buzzer will
sound.
OPERATING INSTRUCTION
MEASURING VOLTAGE
1. Connect the black test lead to the “COM” jack and the red test lead to the “VΩHz” jack.
2. Set the rotary switch to the desired V~ or V range and connect the test leads to the source
