ASSEMBLY INSTRUCTIONS
17
Lowes.com/masterfor
g
e
17. Slide the main burner drip tray (AF)
between the drip tray support (AE) from
the back of grill. (Fig. 17)
18. Attach the battery box (AG) to the left
panel (AB) with screws (CC) and nuts (AA).
(Fig. 18)
17
AF
AE
CC
AA
AG
AB
18
Nut
CC
5/32-32 x 3/8 in.
Screw
X 2
Hardware Used
AA
X 2
