13
Step 13: Attach Grill Body Assembly



NOTE: Two people are needed to perform this step.
Hardware Used
13
G
M6x16
Bolt
CC
x 4
Step 14: Attach Bolts


Hardware Used
14
R
J
Ø16
Washer
FF
x 4
Ø6
Lock Washer
GG
x 4
ASSEMBLY INSTRUCTIONS
M6x22
Bolt
DD
x 3
