Master Forge GBT23010L User Manual

11
Step 9: Place Lid onto Bottom Bowl
Align the holes in the top hinges (C) and bottom
hinges (D). Then insert two Ø5x30 pins (HH) and
Ø1.4x30 cotter pins (II) into the holes shown in
Fig.9.
Hardware Used
9
Step 10: Attach Heat Plate and Cooking Grid
Put the heat plate (F) into place.
Put the cooking grid (E) into place.
10
E
F
ASSEMBLY INSTRUCTIONS
Ø5x30
Pin
HH
x 2
D
C
Ø1.4x30
Cotter Pin
II
x 2
