3. TECHNICAL
MPXI11MULTI4PC17
Mains voltage / frequency 220V-240V~50
Absorbed power 1100 Watt
Speed min
-1
2850
Type of protection / Insulation class F / IP X4
Suction fitting 1"
Delivery fitting 1"
Maximum flow rate 5400 l/h
Maximum head 45 m
Maximum suction height including load losses 8 m
Power cable H07 RNF
Weight 12.8Kg
Maximum dimension of pumped solid particles 1mm
Maximum admitted working pressure 4.5 bar
Minimum ambient temperature 5° C
Maximum ambient temperature 35° C
Maximum temperature of the pumped fluid 40° C
Maximum number of starts per hour, uniformly distributed 40
Noise emission values measured according to relevant standard.
Acoustic pressure level
L
PA
65 dB(A) K = 3 dB(A)
Acoustic power level
L
WA
85 dB(A) K = 3 dB(A)
The sound power pressure
may exceed 85 dB(A), in this
case individual hearing
protection must be worn.
Weighted root mean square acceleration according to relevant standard. : < 2.5 m/s²
The declared vibration total value has been measured in accordance with a standard
test method and may be used for comparing one tool with another that the declared vibration
total value may also be used in a preliminary assessment of exposure.
A warning that the vibration emission during actual use of the power tool can differ
from the declared total value depending on the ways in which the tool is used and of the need
to identify safety measures to protect the operator that are based on an estimation of exposure
in the actual conditions of use (taking account of all parts of the operating cycle such as the
times when the tool is switched off and when it is running idle in addition to the trigger time).
4. IMPLEMENTATION STANDARDS
• IEC/EN 60335-1 Household and similar electrical appliances - - safety
Part 1: General requirements.
• IEC/EN 60335-2-41 Household and similar electrical appliances - - safety
Part 2-41: Particular requirements for pump
