6. PRODUCT STRUCTURE
POS. Part POS. Part
1 Terminal box 10 Diffuser
2 Capacitor 11 Mechanical seal
3 Stator 12 Pump support
4 Pump body 13 Fan cover
5 Reflux cover 14 End plate
6 Pump tube 15 Fan
7 Pump cover 16 Ball bearing
8 Drain cover assembly 17 Rotor
9 Impeller
