Electrical Requirements:
Always follow all local electrical codes when installing our water treatment
equipment.
1. Provide an 120v/60Hz properly grounded dedicated electrical
Outlet. (It’s very important that the polarity be correct)
Avoid using outlets that are switch controlled.
2. Maximum amperage required is 5 amps.
3. Make sure the electrical service provides power 24 hours per day.
We recommend installing a surge protector to protect unit from
power surges, which are not covered by warranty.
Chlorine Tank:
1. The Chlorine tank should be located directly beside the mineral tank.
2. Connect the 3/8" poly tubing to the 3/8” white elbow compression fitting
located on the right side of the Logix control valve.
See Figure Below.
The Chlorine tank is equipped with a 464 shutoff valve, the float height was
preset at the factory.
