NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
© 2014, Pinnacle Products International, Inc. Dual Fusion Forced Air Heater User’s Manual
Maintenance
/RQJ7HUP6WRUDJH
1. Drain fuel through the drain plug in the bottom
of the fuel tank.
2. To remove the drain plug, pull the plug grip
downward and remove the seal head from the
drain hole in the tank. (See Figure 5)
Using a small amount of kerosene, rinse and
swirl the kerosene inside of the fuel tank,
empty the tank fully.
4. To replace the drain plug; push the drain head
fully into the drain hole and secure by pushing
the seal cap fully into the head hole.
(See Figure 6)
,03257$171HYHUVWRUHOHIWRYHUNHURVHQHEHWZHHQ
VHDVRQVXVLQJROGIXHOFDQGDPDJHKHDWHU
Service:
DO NOT TAMPER WITH THE UNIT. HAVE
A COMPETENT SERVICEMAN MAKE ANY
NECESSARY ADJUSTMENT OR REPAIRS.
Use only original equipment parts. The use of
alternate or third party components can cause unsafe
operating conditions and will void your warranty.
We suggest following a maintenance schedule as follows:
)8(/)8(/7$1.
Flush tank every 200 hours of operation or as needed.
'2127ÀXVKZLWKZDWHUXVHIUHVK.NHURVHQHRQO\
Drain Plug
Drain Plug Grip
(Pull Down)
Figure 5
Figure 6
Drain Plug
Fuel Tank
Seal Head
Head Flange
Seal Cap
8
TIP: To order OEM parts call (800)-641-6996
TIP: Follow the long term storage
LQVWUXFWLRQVWRÀXVKWKHWDQN
1HYHUVHUYLFHKHDWHUZKLOHLWLV
SOXJJHGLQRUKRW
WARNING
