HARDWARE LIST
PARTS LIST
STOP
DO NOT RETURN TO RETAILER
For Assembly Assistance, Missing or Damaged Parts
Call: MASTERBUILT Customer Service at 1-800-489-1581.
5
(A)
M5*14
Phillips Screw
Qty: 12
Model 20071011
PART NO REPLACEMENT PART ITEM NO
1 Body Kit 9907100002
2 Door with Window 9907090028
3 Air Damper Kit 990060221
4 Adjustable Screw Leg 910050006
5 Wheel Kit 9907100004
6 Digital Control Kit 9907100001
7 Rear Handle Kit 9907100015
8 Door Latch Kit 990070018
9 Water Bowl 910050030
10 Wood Chip Tray 9007100018
11 Wood Chip Loader 9007090093
12 Drip Pan 910070028
13 Smoking Rack 910050029
14 Door Hinge Kit 9907090041
15 Grease Tray 910060047
16 Leg Boot 910050009
17 Wireless Remote Control 9007100008
18 Meat Probe 9007080006
19 Light Bulb Cover Kit 9907090035
20 Element Kit 9907090033
21 Cooking Grate Support Rack Kit 990050049
22 Wood Chip Lid Kit 9907100013
Element Support Rack 990070020
Grease Tray Bracket Kit 9900500024
Hardware Kit (Control Box) 998050010
Hardware Kit 9907100006
Instruction Manual 9807100037
14
TROUBLESHOOTING GUIDE
SYMPTOM
Power light won’t come on
Unit takes excessive amount of
time to heat up
(longer than 60-70 min)
There is a gap between the door
and the smoker when in use and
door latch has no more
adjustment
Grease is leaking out of smoker
through door and legs
No smoke
Temperature rapidly decreased
or shut down after few hours of
use
Controller displaying error
message
Power light is on, unit isn’t
heating
Controller does not adjust heat
Interior light does not come on
Meat probe temperature does
not show on display
Remote will not control smoker
CAUSE
Not plugged into wall
House fuse tripped
Wire connector on controller not
properly connected to smoker
Controller malfunctioning
Unit plugged into an extension
cord
Door not closed properly
Controller malfunctioning
Door alignment
Damaged door seal
Drip pan not in place
Excess grease or oil build-up in
unit
Drain tube in back of unit is not
draining
No wood chips
Faulty control unit
Controller malfunctioning
Controller/unit malfunctioning
Controller/unit malfunctioning
Bulb burned out
Switch is in off position
Probe malfunctioning
Batteries are weak or installed
wrong
Remote is not linked properly to
controller
Remote malfunctioning
POSSIBLE SOLUTION
Check wall connection
Make sure other appliances are not
operating on the same electrical
circuit. Check household fuses.
See Step 2a on Page 6
Contact Masterbuilt at 1.800.489.1581
Set unit so an extension cord does
not have to be used
Close door and fasten latch securely
Contact Masterbuilt at 1.800.489.1581
Contact Masterbuilt at 1.800.489.1581
Reposition so hole lines up with drain
hole in bottom of unit
Clean unit
Check drain tube positioning at back
of unit
Add wood chips (See Page 11)
Contact Masterbuilt at 1.800.489.1581
Contact Masterbuilt at 1.800.489.1581
Contact Masterbuilt at 1.800.489.1581
Contact Masterbuilt at 1.800.489.1581
Replace bulb with 15W-25W bulb
made for ovens
Turn switch on
Contact Masterbuilt at 1.800.489.1581
Refer to page 13 instructions
Contact Masterbuilt at 1.800.489.1581
