Hardware List
M6x12
Qty.-16
A
M6 Flange Nut
Qty.-16
B
M10 Flat Washer
Qty.-4
C
M10x30 Bolt
Qty.-4
D
E
M5x14
Qty.- 12
F
M4x8
Qty.- 2
DO NOT RETURN TO RETAILER for assembly assistance, missing or damaged parts. Please
contact MASTERBUILT customer service at www.masterbuilt.com/pages/contact-us. Please have the
model number and serial number available. These numbers are located on the silver rating label
on the smoker.
STOP
• BEFORE ASSEMBLY READ ALL INSTRUCTIONS CAREFULLY.
• Assemble on a clean flat surface.
• Tools needed: Adjustable wrench, Phillips head screwdriver
• Approximate assembly time: 25 minutes
• Actual product may differ from picture shown.
• It is possible that some assembly steps have been completed in the factory.
