Masterbuilt GRAVITY 560 Series User Manual

21
11
Insert screw heads on bottom of heat manifold (11) into manifold support.
Slide manifold toward hopper. Tighten screws beneath manifold.
55
26
25
Instal the antenna by screwing it onto the back of the panel.
Then, turn the top portion of the antenna as shown.
Assembly

Masterbuilt GRAVITY 560 Series Specifications

General

Fuel Type	Charcoal
Cooking Area	560 sq. in.
Temperature Range	150°F to 700°F
WiFi and Bluetooth	Yes
Grill Grate Material	Cast iron
Material	Steel
Control Type	Digital
Hopper Capacity	10 lbs
Power Source	Electric
Meat Probe	Yes
