ROUTER TABLE - 054-6938-6
13
Assembly
Attaching the legs to the table top
1. Place the router table surface on a flat, level
surface, with the underside of the table
facing up.
2. Position the legs against the router table
surface, as shown in fig 1.
3. Position one short end of the table so that it
extends beyond the edge of the work surface
far enough to gain access to the four holes in
that end of the top of the router table.
4. Align the two outermost holes on the tabletop
with the holes in the leg bracket.
5. Place a small washer (12) onto each of two
short pan-head screws (8). Insert the short
pan-head screws up through the holes in the
table and through the holes in the leg bracket.
Place a small washer (12), a spring washer
(13), and a small nut (10) on the threads of the
screw. Loosely tighten the nuts (fig 1).
6. Place a small washer (12) onto each of two
long pan-head screws (7). Insert the long pan-
head screws up through the other two holes
on the tabletop and through the corresponding
holes in the leg. Place a small washer (12), a
spring washer (13), and a small nut (10) on
the threads of the screw (fig 2).
7. Tighten all fasteners securely.
8. Repeat with the other leg.
OPERATING INSTRUCTIONS
fig 1
fig 2
