model no. 054-6988-6 | contact us 1-800-689-9928
26
No. Part No. Description No. Part No. Description
1 5610106000 Tapping screw 31 3122997000 Plunge lock lever
2 3320386000 Cover 32 5620346000 Slotted set screw
3 3123273000 Cover 33 3700074000 Spring
4 4900252000 Speed adjuster 34 5630037000 Nut
5 5610017000 Tapping screw 35 3320387000 Left handle cover
6 3122984000 Cover 36 5620013000 Hexagon socket screw
7 5610053000 Tapping screw 37 5650007000 Spring washer
8 3700539000 Epoxy board 38 5650006000 Plain washer
9 3123039000 Brush holder 39 3320388000 Left handle
10 3703641000 Brush bush 40 3420481000 Plunge frame
11 4960250000 Carbon brush 41 5610044000 Tapping screw
12 3122908000 Motor housing 42 5630036000 Nut
13 3121049000 Spring 43 3660030000 Spring
14 3700249000 Washer 44 3700079000 Spindle lock
15 5700008000 Bearing 45 3123040000 Spindle lock button
16 2740236000 Stator 46 3120300000 Lock cover
17 5610049000 Tapping screw 47 5610083000 Thread forming screw
18 2750831000 Rotor 48 3550572000 Collet
19 5660018000 Circlips for shaft 49 5630034000 Lock nut
20 3122985000 Fan baffle 50 3700870000 Wrench
21 5620068000 Screw 51 4860224000 Inner wire
22 3700072000 Bearing clamping plate 52 3320389000 Right handle cover
23 5700017000 Ball bearing 53 3320390000 Right handle
24 5620032000 Screw 54 3120234000 Cord anchorage
25 3120200000 Adjusting knob 55 5610031000 Screw
26 5690002000 O-ring 56 3121050000 Cord guard
27 3123038000 Depth indicator 57 4810002000 Power cord and plug
28 3550750000 Depth adjusting bolt 58 3122983000 Cover
29 3550749000 Depth stop bar 59 4870093000 Switch
30 5620039000 Screw 60 3660166000 Spring
PARTS LIST
