No. Part No. Description No. Part No. Description
61 3550759000 Plunge rod 72 3420482000 Bottom support
62 3123306000 Upper cover 73 5620112000 Slotted set screw
63 5630003000 Hexagon nut 74 3550588000 Guiding rod
64 3123305000 Lower cover 75 3122909000 Base plate
65 3121632000 Bellows seal 76 5620220000 Screw
66 5620103000 Slotted shoulder screw 77 3700872000 Guide bush
67 3700078000 Waver washer 78 5620076000 Screw
68 3420387000 Turntable 79 3700871000 Parallel guide
69 5700046000 Steel ball 80 5650013000 Plain washer
70 3400189000 Lock bolt 81 5650015000 Spring washer
71 3121583000 Chip shield 82 5620050000 Screw
If any parts are missing or damaged, or if you have any questions, please call the toll-free helpline at
1-800-689-9928.
