MasterCraft 054-7120-4 User Manual

ANGLE GRINDER - 054-7120-4
21
No. Part No. Description
1 3550130003 Outer Flange
2 3550328002 Inner Flange
3 3705072001 Guard
4 5620419002 Screw With Washer
5 3550816001 Output Shaft
6 5650044001 Plain Washer
7 3402181001 Gear Case Cover
8 3551363001 Bevel Gear
9 5700053001 Needle Bearing
10 5610094004 Thread Forming Screw
11 3705573001 Bush
12 3660345001 Compression Spring
13 3705795001 Lever
14 5610106003 Tapping Screw
15 3552071001 Spindle Lock
16 3421494002 Gear Case
17 3660235001 Spring
18 3120354001 Pin Knob
19 3121029001 Rubber Ring
20 5630040002 Nut
21 3551368001 Pinion
22 5700008001 Ball Bearing
23 2750998001 Rotor
24 5700004001 Ball Bearing
PARTS LIST
No. Part No. Description
25 3121026001 Bearing Holder
26 3127161001 Fan Baffle
27 5610051006 Tapping Screw
28 2740344001 Stator
29 4870023018 Switch
30 4960245005 Carbon Brush
31 2800020002 Brush Support
32 3660042001 Spring
33 5610010006 Tapping Screw
34 3127160001 Front Housing
35 3124057001 Switch Button
36 5610031002 Thread Forming Screw
37 3703769001 Cord Anchorage
38 4930056003 Terminal
39 4860006004 Inner Wire
40 4860006005 Inner Wire
41 3124058001 Switch Actuator
42 3121045001 Cord Guard
43 3127159001 Rear Housing
44 4810003006 Power Cord & Plug
45 2490136005 Nylon String
46 3402299002 Handle
47 3700567002 Wrench
If any parts are missing or damaged, or if you have any questions,
please call the Toll-free Helpline, at 1-800-689-9928.
