PACKAGE CONTENTS
Belt sander, dust bag, fine belt, coarse belt and instruction manual
KEY PARTS DIAGRAM
1
2
7
6
5
3
4
8
9
No. Part No. Part
1 ON/OFF 2-finger trigger switch 6 Belt adjustment knob
2 “Lock-ON” button 7 3-position adjustable handle
3 Adjustable belt speed knob 8 Cord guard
4 Quick release tension lever 9 Dust collection bag
5 Sander belt
WARNING!
• Remove the sander from the package and examine it carefully. Do not discard the carton or any packaging
material until all parts have been examined.
FPO
KEY PARTS DIAGRAM
