12
model no. 5742 | contact us 1-800-689-9928
OPERATING INSTRUCTIONS
INSTALL THE BIT HOLDER (fig 2)
1. Remove the battery from the tool.
2. Align the rib of the bit holder with the hole on the
base of the cordless impact driver.
3. Insert the screw (included) and tighten the screw
securely with a screwdriver (not included). The
bit holder can be positioned on either side of the
tool.
REMOVE THE BIT HOLDER (fig 2)
1. Remove the battery from the tool.
2. Use a screwdriver (not included) to loosen the screw that attaches the bit holder to the cordless
impact driver.
3. Remove the screw and the bit holder.
INSTALL THE BELT CLIP (fig 3)
1. Remove the battery from the tool.
2. Align the rib of the clip with the hole on the base
of the cordless impact driver.
3. Insert the screw (included) and tighten the screw
securely with a screwdriver (not included). The
belt clip can be positioned on either side of the
tool.
REMOVE THE BELT CLIP (fig 3)
1. Remove the battery from the tool.
2. Use a screwdriver (not included) to loosen the screw that attaches the belt clip to the cordless
impact driver.
3. Remove the screw and the belt clip.
fig 2
Screw
Bit holder
fig 3
Screw
Belt clip
