MasterCraft 054-8332-4 User Manual

20V max* LITHIUM-ION CORDLESS CIRCULAR SAW - 054-8332-4
10
DESCRIPTION
,OPXZPVSDPSEMFTTDJSDVMBSTBX
No. Description No. Description
1 Trigger Switch 9 Bevel-Adjustment Knob
2 Lower Blade-Guard Lever 10 Bevel Scale
3 Blade Screw 11 Auxiliary Handle
4 Blade 12 Lock-Off Button
5 Lower Blade Guard 13 Spindle-Lock Button
6 0° Blade-Guide Notch 14 0° Bevel-Stop Adjusting Screw
7 45° Blade-Guide Notch 15 Depth-of-Cut Quick Adjustment Lever
8 Edge-Guide Locking Knob 16 Depth Scale
13
6
1
3
2
12
5
4
7
8
9
10
11
14
15
16
