20V max* LITHIUM-ION CORDLESS CIRCULAR SAW - 054-8332-4
15
OPERATING INSTRUCTIONS
t
Do not cut warped or wet lumber.
t
Hold the saw rmly with both hands and keep your body in a balanced position to resist the forces if
kickback should occur.
WARNING!
To avoid kickback, release the trigger switch immediately if the blade binds or the saw stalls.
Kickback could cause you to lose control of the saw. Loss of control can lead to serious injury.
Lock-off button
(g 7)
The lock-off button reduces the possibility of
accidental starting. The lock-off button is located
on the handle above the trigger switch. The lock-off
button must be depressed before you squeeze the
trigger switch to start the saw.
NOTE:
The lock-off button can be operated from
either the left or right side.
Starting/stopping the saw
(g 7)
5PTUBSUUIFTBX
1. Depress the lock-off button.
2. Depress the trigger switch. Always allow the blade to reach full speed, and then guide the saw into the
workpiece.
5PTUPQUIFTBX
1. Release the trigger switch.
2. After you release the trigger switch, allow the blade to come to a complete stop. Do not remove the saw
from the workpiece while the blade is moving.
Electric brake
The saw has an electric brake to quickly stop the blade rotation. The electric brake engages when the
trigger switch is released. When the brake is functioning properly, sparks may be visible through the vent
slots in the motor housing. This is normal and is the action of the brake.
WARNING!
If the electric brake repeatedly fails to quickly stop the blade rotation, the saw should be
repaired by a qualified technician.
fig 7
