No. Part No. Description No. Part No. Description
01 3550688000 Flange Bolt 30 3550927000 Pinion
02 3520218000 Outer Flange 31 2730193000 DC Motor
03 3810403000 Blade 32 3321419000 Left Handle Assembly
04 3520316000 Inner Flange 33 3402627000 Contact Receptacle Assembly
05 5660135000 Circlips For Shaft 34 4870429000 Trigger Switch
06 5610103000 Tapping Screw 35 3321418000 Right Handle Assembly
07 3125500000 Lever 36 3321428000 Rear Cover Assembly
08 3126519000 Lower Guard 37 5680028000 Hexagon Wrench
09 3660255000 Spring 38 5690018000 O Ring
10 5640155000 Bolt 39 3125511000 Lock Off Trigger
11 3126517000 Guard 40 3660028000 Stop Spring
12 5650053000 Washer 204 2822952000 Base Plate Assembly
13 3402167000 Lock Rod 41 5680009000 Rivet
14 3122852000 Depth Adjusting Lever 42 3703970000 Depth Bracket
15 5650004000 Plain Washer 43 3703971000 Base Plate
16 4860003000 Inner Wire 44 3704819000 Support
17 5610055000 Tapping Screw 45 5640198000 Bolt
18 3121051000 Stopper 46 5630007000 Prevailing Torque Hexagon
Nut
19 5610030000 Thread Forming Screw 47 5630067000 Wing Nut
20 3421240000 Gear Case 48 5650016000 Plain Washer
21 3660244000 Spring 49 5640019000 Square Neck Bolt
22 3402337000 Spindle Lock 50 5630003000 Hexagon Nut
23 5700048000 Ball Bearing 51 5620076000 Screw
24 5660020000 Circlips For Hole 52 3660071000 Spring
201 2822711000 Gear Set 53 5640047000 Wing Bolt
25 3550928000 Gear Shaft
26 3550926000 Gear
27 5620483000 Screw
202 2823178000 Gear Case Cover Assembly
28 5700163000 Oil Impreg Bearing
29 3421280000 Gear Case Cover
203 2822713000 Motor Gear Assembly
29
20V max* LITHIUM-ION CORDLESS CIRCULAR SAW - 054-8332-4
PARTS LIST
