7 1/4" CIRCULAR SAW - 054-8357-67 1/4" CIRCULAR SAW - 054-8357-6
MAINTENANCE
6. Use the lower blade guard lever to retract the lower blade guard into the upper blade guard. Make sure
that the lower guard spring works properly and allows the guard to move freely.
7. Verify that the saw teeth, the arrow on the saw blade and the arrow on the lower guard are all pointing in
the same direction.
NOTE:
The saw teeth should point upward at the front of the saw, as shown in (g 6).
8. Fit the saw blade inside the lower blade guard and onto the spindle.
9. Replace the outer blade ange.
10. Depress and hold the spindle-lock button, and replace the blade screw.
11. Tighten the blade screw securely by turning it clockwise with the wrench.
NOTE:
Never use a blade that is too thick to allow the outer blade ange to engage with the at section of
the spindle.
PROBLEM POSSIBLE CAUSES SOLUTIONS
The circular saw does
not work.
The saw is not connected to a power source. Connect the plug to a power source.
The blade does not follow
a straight line.
The teeth are dull. This is caused by hitting a
hard object such as a nail, dulling teeth on one
side. The blade tends to cut to the side with the
sharpest teeth.
Replace the blade.
The edge guide or straight edge is not being
used.
Use an edge guide or straight edge.
The blade binds or
smokes from friction.
The blade is dull. Replace the blade.
The blade is on backwards. Install the blade correctly.
The blade is bent. Replace the blade.
The workpiece is not properly supported. Clamp the workpiece correctly and tightly.
The incorrect blade is being used. Use the correct blade.
If the problem remains unsolved after performing the checks described above, call the toll-free helpline at
1-800-689-9928.
TROUBLESHOOTING
