MasterCraft 055-5530-8

PACKAGE CONTENTS
No Description Qty Illustration
Head assembly
Base
Table/support assembly
Crank handle
Chuck
Feed handles
Rack
Column/support assembly
1
2
3
4
5
6
7
8
1
1
1
1
1
3
1
1
model no. 055-5530-8 | contact us 1-800-689-9928
17
ASSEMBLY INSTRUCTIONS
16
KNOW YOUR DRILL PRESS
Motor:
Your drill press is equipped with an industrial-duty induction motor for long-lasting, smooth performance.
Table:
The table of your drill press rotates 360˚ and bevels up to 45˚ for angle drilling.
LED worklight (3.2-3.4 V):
The drill press comes equipped with an LED worklight that lights the work area for more accurate cuts. The
worklight turns on with the LED worklight switch.
