WARNING!
If any parts are damaged or missing, do not operate this tool until the parts are replaced. Use of
this product with damaged or missing parts could result in serious personal injury.
• Do not attempt to modify this tool or create accessories not recommended for use with this tool.
Any such alteration or modification is misuse and could result in a hazardous condition leading
to possible serious personal injury.
• Do not connect to power supply until assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
• Risk of injury! Always pull out the mains plug (disconnect the product from its power supply)
before commencing work on the product.
• To avoid fire or toxic reaction, never use gasoline, naptha or similar highly volatile solvents.
No Description Qty Illustration
Rack collar
Flat washers M8
Spring washers M8
Bolts M8x25
Batteries
3 mm/4 mm Hex key
Chuck key
9
10
11
12
13
14
15
1
3
3
3
2
2
1
TOOLS NEEDED FOR ASSEMBLY
Star-head screwdriver Framing square
Block of wood Ruler
Wrench Hammer
UNPACKING
Do not use this product if any parts of the package contents are already assembled to your product when you
unpack it. Package contents are not assembled to the product by the manufacturer and require customer
installation. Use of a product that may have been improperly assembled could result in serious personal injury.
• Inspect the tool carefully to make sure no breakage or damage occurred during shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily operated the tool.
• Remove the protective oil that is applied to table, base and column. Use any ordinary household grease
and spot remover.
• Apply a coat of paste wax to the table, column and machined surfaces of base to prevent rust.
Wipe all parts thoroughly with a clean, dry cloth.
• If any parts are damaged or missing, please call 1-800-689-9928 for assistance.
model no. 055-5530-8 | contact us 1-800-689-9928
