MasterCraft 055-6717-0 - Table of Contents

2
TABLE OF CONTENTS
Rules for Safe Operation……………………………..………………. Page 3
Glossary of Woodworking Terms………………………………………Page 8
Description…………………………………………………….............Page 9
Assembly……………………........…………………..........................Page 11
Adjustments....................………………….........................................Page 13
Operation...................………………………………...........................Page 14
Maintenance.............................…………………................................Page 23
Troubleshooting...........................………………….............................Page 23
Repair Parts...................................…………………...........................Page 25
Exploded View & Part List................………………............................ Page 26
Warranty……………………………………………………….……..Page 30
SPECIFICATIONS
Mitre Saw Specifications :
Motor: 120 V 60Hz 15 A,
Speed: 5500 RPM (no load)
Blade size: 10 (25.4 cm.) (40-tooth) carbide-tipped
Arbour size: 5/8” (15.9mm)
Weight: 29.6 lbs (13.4kg)
Cutting capacity:
2 5/8 x 5 1/2” crosscut at 0° mitre, 0° bevel
2 5/8 x 3 1/2” mitre at 45° mitre, 0° bevel
1 1/2 x 5 1/2” bevel at 0° mitre, 45° bevel
1 1/2 x 3 1/2” compound at 45° mitre, 45° bevel
